TM1934 LED Strip
TM1934 LED strip is an innovative addressable SMD LED strip lighting solution which is designed to provide dynamic and customizable lighting effects. A wide range of applications, from architectural lighting to stage and event lighting.
This TM1934 pixel protocol was designed by Titan Micro Electronics in China. It offers a redundant data line to allow a continuous data path even if a single pixel fails. The control circuit comes in a SOP8 package, allowing for more flexibility with LED choice.
The TM1934 PWM rate is 666Hz, data transfer speed is 800kbps and supports 3 channels. It can be designed to DC5v, DC12v and DC24v addressable RGB LED strip.
The TM1934 is a 4-pin addressable LED strip IC with redundant data signals, compatible with both 12V and 24V operating voltages. As a fixed IC chip external to the LED package, a single TM1934 can simultaneously control all LEDs within a single cutout area and can be programmed for RGB/CCT/white color via an SPI-compatible controller.
As a non-individually addressable LED strip, the TM1934’s color rendering is directly affected by the number of ICs on the flexible PCB strip. A higher number of ICs significantly enhances the nuance and richness of color. TM1934 LED strip has superior lighting effects for both indoor and outdoor projects.
The TM1934 4-wire LED strip maintains signal integrity over longer distances compared to 12V DC driven WS2815, SK6813, WS2818, GS8208 and 5V low voltage driven WS2813 LED strip lighting.
Since FW1935 and TM1934 have essentially the same characteristics, they are considered one. If you want more details about both, please click to view. WS2818B vs FW1935/TM1934 vs FW1834.
TM1934 60 LEDs/m DC 12V LED Strip Advantages from Suntechlite, please click here.
Types of TM1934 Break Continue LED Strip
Product Features
Breakpoint resume function: This TM1934 digital light can automatically detect the breakpoint location, and resume work at the interrupted point to ensure the normal operation of the entire light strip.
Multiple installation options: This strip can be installed using a variety of methods, including adhesive tape, clips, or mounting brackets.
Customizable length: The TM1934 LED tape light can be customized to specific lengths, 12v is 3leds per cut at 50mm, 24v is 6leds per cut at100mm.
Waterproof: The TM1934 RGB LED strip is available in waterproof versions of IP65/IP67/IP68, making it suitable for outdoor or damp environments.
TM1934 LED Strip Applications
Residential lighting:
Restaurant and bar lighting:
Hospitality lighting:
Stage lighting:
Backlighting:
LED Strip Accessories
Cable Connectors
Controllers Recommended
Why Choose SunTechlite FW1935 LED Strip
We are a Chinese factory specializing in the design and production of pixel-addressable LED strips. We specialize in customizing LED pixels and LED neon products. With over 15 years of experience in customizing and producing high-quality LED products, we ensure our customers are satisfied with our service and products. Our TM1934 series addressable strips offer the following advantages over other manufacturers:
For more details, please click TM1934/WS2818/FW1935 LED Strip Advantages.
Full Solder Joints
Backside Lamination
Signal input Protected
Signal output Protected
Genuine 3M Adhesive
National Standard Wire 1.8mm/20AWG
Wire Diameter is 0.15mm*26pcs
PCB Board Thickness is 35+70 oz copper
