Thinnest LED Strip
What is ultra narrow LED strip? normally flexible LED strip PCB is 8mm, 10mm, 12mm width. For some positions, we need strip ultra thinner, such as 2.5mm, 3mm, 4mm ,5mm or 6mm width PCB, these slim LED strip we name as thin LED strip. Can be compatible with slim neon LED tube or quite thin aluminium profiles for different applications.
DC12v or DC24v are for options, single color different color temperatures such as 2700k, 3000k, 4000k ,5000k, 6000k for options. RGB color and CCT tunable ultra slim LED strip for choices as well.
These strips could be PWM controlled or Tuya app control quite easy for making different slim visual impact. Can be 0~100% dimmable.
PCB Width: 2.5mm
LED Density: 156LEDs/m
Power: 4W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 2.5mm LED strip is the thinnest tape light we have; unique PCB design can ensure not break while in installation. Different color temperatures for options, RED, GREEN, BLUE, YELLOW as well. We also accept customized length such as 1 meter per piece, normal is 5 meters per roll. High density 156leds per meter means dot less in neon tube or aluminium profiles. Each 3 leds could be cut conveniently DIY creation.
PCB Width: 3mm
LED Density: 120LEDs/m
Power: 4W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
3mm LED strip is designed for applications where space is at a premium and flexibility is a must. Their compact size and high flexibility allow for innovative lighting solutions such as Accent Lighting, Backlighting, Wearable and Portable Devices, and Art and Decorative Projects. Currently, the strip is 4 watts per meter, if you need brighter, the brightness could be customized as well.
PCB Width: 3mm
LED Density: 120LEDs/m
Power: 5W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
3mm 12v LED strip will have a voltage drop after 5 meters run, if you need longer same brightness then this DC24v 3mm 120 leds per meter slim strip is perfect. With high density and 5 watts per meter, this strip is brighter and looks uniform and has linear lighting after installation. Every 6 leds could be cut, creating seamless and subtle lighting effects in both residential and commercial spaces.
PCB Width: 4mm
LED Density: 60LEDs/m
Power: 5W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
If the space can fit this 4mm LED strip, it is quite cost-effective to use the 60 leds per meter LED strip. The flexibility of these LED strips also means they can be bent and shaped to follow curves and contours, making them ideal for custom lighting designs. 5w per meter is low power consumption so less heat is generated and a longer lifespan of 50000 hours.
PCB Width: 4mm
LED Density: 90LEDs/m
Power: 6W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
Normally the thin LED strip is 5mm width PCB, if you need thinner one then this 4mm width PCB is your good choice. With different color temperatures for options such as 1800k golden color, 2700k warm white, 4000k natural white, and 5000k daylight. We have RED, BLUE, and GREEN colors as well other than the white slim strips.
PCB Width: 4mm
LED Density: 120LEDs/m
Power: 6W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
120leds per meter 4mm LED strip is dotless if the alumiunium profile height is higher than 10mm, if uniform lighting depends on the distance from the strip lighting source to the surface needs to be illuminated. If you need professional advice, please feel free to contact us. It is a highly versatile lighting solution characterized by the 4mm width narrow width and flexibility, allowing them to be installed in tight spaces where traditional LED strips might not fit, making them one of the thinnest LED strips available on the market. ​
PCB Width: 4mm
LED Density: 132LEDs/m
Power: 6W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
132 leds per meter are the highest density that we can supply at 4mm width PCB ultra narrow strip light. If the height is more than 9mm the aluminium profile can all fit this strip to ensure uniform lighting and dotless. Furthermore, if you make this with a silicone tube which is a smart choice, for mini silicone neon tube, we can recommend it. Ultra thin 4mm PCB makes it easy to cross the neon tube light for DIY work
PCB Width: 5mm
LED Density: 60LEDs/m
Power: 5W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
60leds 5mm width strip is a classic type of ultra slim strip light in the market. 12v means each 3 LED cuttable is easy for installation job, 60leds per meter can save extra material cost so the most cost effective one, if the distance between the strip and surface that to be illuminated more than 20mm, then you can choose this type so dotless and nice looking. SMD2835 one bin supply proves each time the same color for continuing projects in different positions.
PCB Width: 5mm
LED Density: 60LEDs/m
Power: 5W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 5mm width 24v LED strip we make at 5 watts per meter so no hot in job to ensure a long lifespan of 50000 hours and 5 years warranty. 99.9% golden wire San ‘an or Epistar chip in the SMD2835 LED, thereby potentially increasing the lifespan of the LEDs due to better thermal management and high quality materials used.
PCB Width: 5mm
LED Density: 120LEDs/m
Power: 9W/m
Voltage: 5V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
You can see 5mm 12v strip in the market easily, while 5v LED strip in 5mm width is not easy to look for. This strip we customized the PCB and launched new to the market for clients used in 5v applications such as computers, cars, TVs, Gaming Setups, Portable and Mobile Applications, Home Decor and Under-Cabinet Lighting. One LED one cut is quite convenient in installation or DIY creation.
PCB Width: 5mm
LED Density: 120LEDs/m
Power: 5W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP65
The 5mm width PCB ultra-thin design allows these LED strips to be installed in narrow or confined spaces where traditional lighting solutions may not fit. This opens up new possibilities for creative and functional lighting designs. Tunable white LED strips design can adjust the color temperature from warm white to cool white and everything in between. This allows for customization of the lighting atmosphere according to the desired mood or activity in a space.
PCB Width: 5mm
LED Density: 120LEDs/m
Power: 5W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
Tunable CCT (Correlated Color Temperature) LED strips offer the unique feature of adjustable color temperature, allowing users to customize the lighting atmosphere according to their preferences or needs. This thin CCT LED strip is compatible with PWM control way easy to find relative controllers in the market. Or you can check here the dimmer controllers.
PCB Width: 5mm
LED Density: 120LEDs/m
Power: 9W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
The 5mm width 600 leds per roll strip light is a typical slim strip in the market, mature and widely used in various applications. For each 3 led cuttable, various single color options such as GREEN, RED, BLUE, 3000k, 4000k, 5000k, 6000k, 10000k, or customized color temperatures as required. 5mm width makes ultra-slim flexible LED strips a preferred choice for innovative lighting projects that require a blend of aesthetics and functionality.
PCB Width: 5mm
LED Density: 120LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
We also developed 24v 120leds per meter 5mm width LED strip, which can work longer distances for example 10 meters same brightness compared to 12v which can only work 5 meters long distances. Each 6leds cuttable namely each 50mm cuttable can mostly fit different conditions. Can select warm white 3000K, neutral white 4000K, and daylight white 6000K.
PCB Width: 5mm
LED Density: 144LEDs/m
Power: 9W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
5mm 144leds strip is our newly launched product that can fit lower height aluminum not higher than 9mm with uniform lighting and dotless looking. each 3leds cuttable namely each 21mm cuttable. Ideal for cabinet lighting which needs slim cut and slim width strip light. Due to their slim profile, these LED strips can be installed in tight spaces without affecting the structure or aesthetics of the cabinetry. They emit very little heat, making them safe to touch and minimizing the risk of fire.
PCB Width: 5mm
LED Density: 168LEDs/m
Power: 9W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 168leds per meter super narrow 5mm width strip can ensure 8mm height aluminum profile no dot and linear lighting. Each 3 leds cuttable namely 18mm cuttable as one unit. The flexibility of LED tape lighting means it can adapt to various under cabinet spaces, including those without an edge or recessed cabinets. This adaptability enhances the lighting’s effectiveness and the aesthetics of the space.
PCB Width: 5mm
LED Density: 168LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 168leds per meter super narrow 5mm width strip can ensure 8mm height aluminum profile no dot and linear lighting. Because of 24v input, every 6 leds cuttable namely 36mm cuttable as one unit. Despite their small size, ultra slim LED strips are equipped with very bright LED chips. They offer a significant amount of light, ensuring that workspaces are well-lit. Their durability also means they have a longer lifespan, reducing the need for frequent replacements.
PCB Width: 5mm
LED Density: 168LEDs/m
Power: 7W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
CCT LED strip can adjust color temperature ranges from warm white (soft white 2700K) to bright white (5000K) offers versatility in applications, enhancing mood, ambiance, and functionality in different spaces. They can dynamically shift between cool to warm lighting, providing flexibility for various settings such as residential, commercial, or artistic environments.
PCB Width: 5mm
LED Density: 168LEDs/m
Power: 7W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 168leds per meter tunable LED strip is designed in 5mm width with super narrow PCB 7watts per meter and 700lm brightness is usually enough for a narrow space illumination. DC24v design, each 6 leds cuttable namely each 3.6mm cuttable. Combining warm white and cool white it could dim from 1% to 10% with regular PWM controllers in the market.
PCB Width: 5mm
LED Density: 180LEDs/m
Power: 9W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
900leds on 5 meters 5mm strip make the strip very high density, if the led strip to a surface distance of less than 8mm, then this density LED strip is the right choice to make dotless illumination. For home decoration to enhance the aesthetic appeal and functionality of living spaces. They are used under cabinets, along staircases, behind televisions, and in coves to create ambient lighting.
PCB Width: 5mm
LED Density: 180LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
5mm warm white ultra narrow LED strip with 180leds per meter namely 900leds per 5 meters a roll. 33mm cuttable. Short is popular for automotive applications, including interior mood lighting and exterior enhancements for cars, motorcycles, and boats.
PCB Width: 5mm
LED Density: 240LEDs/m
Power: 9W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
240leds/m is the highest density LED strip we can supply, if the distance from the lighting source to the surface needs to be illuminated higher than 6mm width, then can fit very well. Each 12.5mm cuttable, namely 3leds one cut. Can be used for various creative projects, leveraging their ability to bend and cut to fit intricate designs and spaces.
PCB Width: 5mm
LED Density: 240LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 240leds per meter strip namely 1200leds per roll 5 meters is the highest ultra narrow LED strip in the market. 9 watts per meter can get a very high brightness of 900lm per meter. They offer a significant amount of light, ensuring that workspaces are well-lit. Their durability also means they have a longer lifespan, and are available for the need requirements for frequent turning off and on.
PCB Width: 5mm
LED Density: 240LEDs/m
Power: 9W/m
Voltage: 12V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
5mm width with high density 240leds/m tunable strip is our new launched to market. it can be used in various applications, including under cabinet lighting, accent lighting, and task lighting, offering flexibility in design and functionality. DC12v design each 6 leds cuttable namely each 2.5m could be cut. Users have the flexibility to create customized lighting scenes that can be easily adjusted for different tasks or preferences.
PCB Width: 5mm
LED Density: 240LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 240leds per meter CCT strip is 12leds as one unit, 6leds warm white, the other 6leds Cool white, can be dimmed from 1% to 100%, allowing for a more uniform single warm lighting or cool lighting illumination and natural white lighting when lit with these two color temperature LEDs, while providing higher brightness. Controllers are easy to find in the market as well.
PCB Width: 6mm
LED Density: 120LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
6mm strip is not quite thin, but not standard in the market, if your aluminum profile is 6.5mm in width, then this 6mm strip light is perfect for the installation, fixed and robust inside, with linear and uniform lighting. Can be dimmed with PWM controllers. With San ‘an LED chip that reaches to 50000 hours lifespan. We offer 3 years to 5 years warranty.
PCB Width: 6mm
LED Density: 140LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
This 6mm LED strip has higher brightness due to its compact design of 2835 SMD with a high density of 140 leds/m, making it more suitable for small spaces and high brightness requirements. Customizable color temperatures are 1800K, 2700K, 3000K, 4000K, 5000K and 6000K. This light strip is currently the promotional model of Suntech Lite and has the most suitable factory price.
PCB Width: 6mm
LED Density: 168LEDs/m
Power: 9W/m
Voltage: 24V
Color: 1800K / 2700K / 3000K/ 4000K/ 5000K/6000K
Waterproof Grade: IP20
If you are looking for the most economical white LED strip, then this 168 leds/m 6mm LED strip can be considered. Don’t worry about the obvious voltage drop due to the high density of 168 LEDs/m. After testing, 24V voltage can completely solve the voltage drop problem. 5M/Roll is the standard specification of this light strip. Discounted prices for large quantities.
PCB Width: 5mm
LED Density: 120LEDs/m
Power: 9.6W/m
Voltage: 12V
Color: RGB
Waterproof Grade: IP20
Normal RGB LED strip 30leds per meter or 60leds per meter. Now we have RGB LED strip 120leds per meter very high density, but ultra slim PCB width mm, With the red, green, and blue channels, you can mix to achieve the desired visual impact to clients. Every 25mm/3 LEDs is cuttable, allowing you to customize the strip length to fit a specific project.
