Neon Size: Small Round Neon Light 13x13mm， inner LED strip PCB width is 5mm.
LED Strip Inside:
SPI control: W2815White or TM1934 RGB or W2815 RGB LED strip
LED Quantity: 120 LEDs per meter
LED Strip Option:
TM1934 LED strip RGB 120leds/m 10pixels/m 5mm width 14.4w/m DC24v
WS2818 LED strip RGB 120leds/m 10pixels/m 5mm width 14.4w/m DC24v
WS2815 White strip 120leds/m 120pixels/m 5mm width 17.2w/m DC12v
W2815 LED strip RGB 120leds/m 120pixels/m 5mm width 17.3w/m DC12v
Color: Addressable RGB / White
Waterproof Level: IP67 Waterproof rating, suitable for indoor and outdoor LED lighting projects.
Length: 5 meters or customized
LED Chip Type: SMD3535, SMD2835, SMD 5050
IC Type: TM1934/WS2818/WS2815
Working Temperature: -4°F (-20°C) ~ 122°F (50°C)
Storage Temperature: -40°F (-40°C) ~ 176°F (80°C)
Input Voltage(V): 12/24V DC
Working Power: Not big than 17w per meter
Material: Silicone, anti-UV, not turn Yellow
Lifespan: 50000 hours, is longer than ordinary PVC Rubber Tube. Weather Resistance, Anti-UV, perfect heat dissipation.
Warranty: 3 years / 5 years
Parameters
| Model | Color | Beam Angle | Neon Tube Size | Voltage | Working Temperature |
|---|---|---|---|---|---|
| STNE-270D-13R | RGB/White | 270 degrees | Φ13mm | DC12V/24V | -20℃～70℃ |
For high quality neon lighting with DMX control, please click DMX512 Pixel LED Neon to view more.
Samll Addressable RGB Neon Strip Lighting
∗ For more types of RGB LED neon lights, please click Addressable LED Neon Strip.
Round 13mm Mini LED Neon Light Features
Product Detailes
Small Round RGB LED Neon Light
LightingDirection:270°
Cuttingmark: Yes
Accessories:
Installation:
First: Prepare the screws and mounting clips
Second: Adjust the fixed clips to the appropriate place, and use a screwdriver to fix the screw.
Third: Put the light-emitting surface upwards, then insert the LED strip into the fixed clips.
Fourth: Fix the neon strip completely into the fixed clip.
Addressable Mini Round LED Neon Application
Themed parties: Neon-themed parties or 80s-themed parties.
Trade shows and exhibitions: Trade shows, exhibitions, and other promotional events.
Restaurants and cafes: Restaurants, cafes, and other food and beverage establishments.
Retail window displays: Window displays for retail stores.
Stage lighting: Colorful stage lighting effects for concerts, theater productions, and other performances.
Pool lighting: Pools, hot tubs, and other water features.
