WS2815 DC12V Flexible RGBIC Addressable LED Panel Sheet

Product Code: ST-51224305-2835-RGBW

Technical Parameters

Voltage: 12V

Power: 15.3 W/PCS

LED Qty: 150 LEDs/PCS

Color+Lumen Flux: RGB+615 Lm/PCS

Light Efficiency: 40.2 Lm/w

PCB Size: 515*300 mm

Product Description

This WS2815 DC12V flexible RGBIC addressable LED panel sheet contains 150 LEDs per sheet. Brightness is 615 lm/pcs. The 15×10 pixel WS2815 flexible LED sheet allows individual control of each LED.

This LED panel sheet can be twisted to fit practically any curved surface due to its flexible backing. The thin, flexible shape makes it excellent for backlighting under-cabinet lights, display stands, and retail displays. Animations, games, and interesting electronic textile crafts can be made with it.

Each pixel of the WS2815 LED RGBIC sheet is individually addressable and has a breakpoint resume function. If one LED is damaged, it will not affect the normal operation of other LEDs. Click for more breakpoint resume LED strips.

Caution: Repeated/excessive bending may significantly reduce the structural integrity of the flexible panel. It is recommended not to apply excessive force when bending it onto curved surfaces to avoid damaging the LED circuitry or the panel itself.

Note that this RGB programmable color LED sheet cannot be cut.
