Flexible RGBW High Density Cuttable LED Panel Sheet
Product Code: ST-51224305-2835-RGBW
Technical Parameters
Voltage: 24V
Power: 40W/PCS
LED Qty: 512 LEDs/PCS
PCB Size: 635*304.8 mm
CRI: >90
Color+Lumen Flux: RGBW+2800 Lm/PCS
Light Efficiency: 70 Lm/w
Dimensions: 24V 1LEDs/39.68*38.1mm
Product Description
This RGBW high density cuttable LED strip light panel sheet emits uniform light across an entire surface. Customization, flexibility, and dynamic color changing. Used for backlighting applications such as marble countertops, display cases, translucent walls, signage boxes, and advertising displays.
The back of the sheet features 3M double-sided tape and screw holes for easy installation. It easily adapts to flat, curved surfaces, or tight spaces. The minimum cuttable size for this 24V RGBW strip light panel is 39.68 x 38.1mm.
Compared to a traditional single-color LED sheet, RGBW offers a richer color spectrum to enhance your surroundings. Besides RGB mixing, this strip light panel delivers 3000K white light for various color temperatures. A color-changing and dimming LED controller is available.
This energy-efficient pixel LED RGBW strip light panel lights your space with up to 2800 lumens and 40W per panel.
Note:
It is recommended that the distance between the light sheet and the diffuser be at least 3cm to achieve a spot-free effect. This 24V 512LEDs/PCS RGBW color-changing constant voltage soft panel achieves smooth and uniform dimming across the entire light sheet. Create an elegant and consistent lighting effect.
Enhances the visual appeal of architectural details and creates mood lighting in interior spaces. How to Cut and Connect LED Sheets
SMD2835 RGBW 16x8x4 512 LEDs, 635mm*304.8mm Flexible Light Pannel, 24V DC Ultra Thin LED Light Sheet – 128 Circuit Areas
For easy installation, these paper-thin LED light sheets have surface-mount connectors and adhesive labels on the back. You can trim the flexible light sheets to various sizes or shapes following the supplied cut lines in either direction.
These LED backlighting sheets are manufactured using a double-layer circuit board and lead-free SMT technology for excellent stability.
Product Features
1. The flexible panels use 2835 SMDs as light sources. Their high density produces uniform illumination without dark areas or hot spots.
2. Large size:635mm*304.8mm. They can be interconnected via connectors mounted on an FPC board.
3. Can be connected to a dimmable driver, dimmer or controller to freely adjust the brightness.
4. IP20 waterproof rating. Use in dry environments only.
5. They come with connectors so you can easily connect multiple light pieces together without soldering, especially useful for larger projects.
6. In addition to RGBW, we also provide static monochrome, dual white, RGB, RGB+CCT, monochrome with lens and addressable colors LED sheets.
Flexible RGBW High Density Cuttable LED Panel Sheet Pictures
