170 Degree Wider Beam Angle Lensed Optical LED Strip For Light Box Signage Illumination
This 170 degree wide angle lens LED strip light is used in display cases and signage. Its optical lens design is to make the light distribution more even, thus creating a soft and professional visual effect.
Key Features
1. High-Precision Optical Lens Technology
The lenses scatter the light and the originally sharp light source is converted to a soft, uniform glow to achieve a high quality, shadow-free effect.
2. 170° Ultra Wide Beam Angle
Thanks to its large 170° beam angle, it provides perfect uniformity without “zebra stripes” or dark spots, even in ultra-thin light boxes or cramped installation environments.
3. Good CRI & True Colour Reproduction
This strip also gets colours right with a CRI of 80-90+. It makes every detail clear in the beautiful natural veins of marble and onyx.
4. Highly Customisable & Flexible
Flexible PCB can be easily bent around any curve, to achieve easy installation. They are cut to size as requested, and are cut exactly to size required.
5. Flicker-free and Safe Dimming
It is safe to touch as it is low voltage operated. It also offers flicker free dimming for smooth dimming and is compatible with modern smart lighting systems.
Why Choose 170° Wide Beam Angle Lensed LED Strip?
- Flawless uniformity, no zebra stripes
The 170-degree optical lens ensures a smooth overlap of light, eliminating the dark spots and “zebra stripes.” It guarantees absolute uniformity also in ultra thin light boxes or in narrow spaces. - Cost Effective & Efficient
Ultra-wide coverage enables wider mounting pitch between rows. This cuts the total number of strips required by 20%-30%, saving significantly on both material and labour costs. - Visual Comfort & True Colours
Faithfully restores graphic vibrancy with high CRI>80 chips. The light is diffused and glare-free, adding a softness and premium look that will naturally draw the passerby’s eye.
Quality Promise & Customisation
We care a lot about your brand colours. Strict control of the colour tolerance to ensure no deviation of colour in bulk purchase. We also provide extensive customisation options for PCB width, wires and wattage to fit your project needs.
Broad Applications
- Advertising, Commercial
Great for big light boxes, subway signs, fabric ceilings. The perfectly uniform light makes your graphics evenly lit from all angles, ensuring your brand stands out to everyone who walks by. - Luxury Interior Decoration
Perfect for backlit stone walls and bars. It subtly emphasises natural textures, without harsh hotspots, turning common stone into a beautiful, luxurious masterpiece. - Professional and Display Lighting
Suitable for soft light boxes and high-quality display cabinets. This type of non-glare high colour rendering index lighting can recover the true colour and generate a high quality ambiance.
Specification Comparison Table
| Feature | 1. White Lens Strip | 2. Tunable White Lens Strip | 3. White LED Lens Panel |
|---|---|---|---|
| Beam Angle | 170° (Ultra-Wide) | 170° | 170° |
| LED Density | 18 LEDs/m | 24 LEDs/m | 180 LEDs (per panel) |
| Form Factor | Linear Strip (20mm width) | Linear Strip (20mm width) | Planar Sheet (500*250mm) |
| Key Application | Standard Light Boxes & Signage | Photography & Dynamic Ambience | Translucent Marble & Onyx |
| CRI | 90+ | 90+ | 90+ (High Fidelity) |
LED Strip with Lens Products
PCB Width: 20 mm
LED Density: 18 LEDs/m
Power: 18 W/m
Voltage: 24 V
Color: 1800K/2700K/3000K/4000K/5000K/6000K
Waterproof Grade: IP20
Wide-angle, backlit, flexible-lens LED light strips are designed for large, irregularly shaped light boxes and stretch ceilings. A 170-degree optical lens provides soft, wide, and even illumination. The flexible PCB allows for flexible installation on curved or irregular surfaces. Cutting can be done at designated locations between each LED. Customize the length of the LED strip to meet your project needs.
PCB Width: 20 mm
LED Density: 28 LEDs/m
Power: 24 W/m
Voltage: 24 V
Color: 1800K/2700K/3000K/4000K/5000K/6000K
Waterproof Grade: IP20
Due to its flexibility, it can be installed in a variety of complex spaces. Include narrow or corner areas. A high degree of installation flexibility. For spaces requiring complex designs or custom shapes, such as home decor, curved walls, or artistic lighting installations. Create a special ambiance. The softer light is excellent in more complex lighting designs. More high-end visual effects.
Voltage: 24V
Power: 20W
LED Qty: 98 pcs
PCB Size: 500*250mm
CRI: >80
Color+Lumen Flux: White
Light Efficiency: 95 Lm/w
Dimensions: 24V 35.71*35.71mm
The 24V flexible LED panel sheet with optical lens for marble illumination has a color rendering index of up to 90, and the colors are lifelike. A variety of color temperatures are available, including 2700K, 3000K, 3500K and 6000K.
Installation Tips
- Clean up the Surface
Make sure the surface you’re mounting to is clean, dry and free of dust for maximum adhesive strength. - Use Correct Power Supply
Use a matching DC12V or DC24V power supply for the output. Reserve 20-30 % additional power capacity for smooth operation. - Polarity check
Check positive (+) and negative (-) terminals before connecting to prevent damage. - No Sharp Bending
The circuit and optical structure should not be sharply bent near the LEDs or lenses. - Change Spacing to Uniform
Depth of light box to spacing of strips. More dense spacing for thin, light boxes, wider spacing for deeper ones.
Something You Need to Know
Question: Can I cut this LED light strip down to the size I need for my project?
Answer: Yes. You can cut it to the specific size at the marked positions. You can read this blog for more details: Where and How to Cut LED Strip Safely
Q: What will I see on my display screen, single LED dots or strip patterns?
Answer: No! 170° Wide Beam Angle = Full Diffusion of Light. So you will see soft and uniform light without any visible LED dots or dark spots.
Question: Can this bulb be used to light up agate or natural stone?
Answer: Yes. Our light strip has high colour rendering index (80-90+), can perfectly reproduce bright colours and textures, and avoids glaring light spots.
Q: What is the voltage of this LED strip? Is it safe?
A: It runs on a safe, low voltage. This makes it completely touch safe for different installations and fully compatible with most of the modern flicker-free dimmers and smart systems.
Q: Where can I use this LED strip?
A: Very multi-purpose. Ideal for commercial advertising (light boxes, subway signs), luxury interior decor (backlit walls, onyx bars) and professional displays (jewellery cabinets, photography softboxes).
